Tipusok: GSH-80IRA (megszűnő tipus), GSH-100IRA (megszűnő tipus), GSH-120IRAB-3, GSH-140IRAB-3, GSH-160IRAB-3
Jellemzők:
- Nagy hatékonyságú lemezes hőcserélő
- Felhasználóbarát vezérlő
- Könnyű telepítés és karbantartás
- PFC vezérlő technológia
- BLDC motor vezérlő technológia
| Nominal input | (indoor only) | 220-240/1/50 | V/Ph/Hz |
|---|---|---|---|
| Liquid side diameter | 3/8" / 9,52 | inch / mm | |
| Gas side diameter | 5/8" / 15,9 | inch / mm | |
| Cooling (fan-coil unit) | Outflow water temp. | 42941 | °C |
| Cooling (floor cooling) | Outflow water temp. | 18 - 25 | °C |
| Heating (fan-coil unit) | Outflow water temp. | 25 - 55 | °C |
| Heating (floor heating) | Outflow water temp. | 25 - 45 | °C |
| Pump | Type | Water-cooled | ' |
| Power input | Pump | 200 | W |
| No. of speed | Pump | 3 | ' |
| Water flow (limit) | Pump | 7,5 | Lit./min. |
| Volume | Expansion Vessel | 10,0 | Liters |
| Water Pressure (Max) | Expansion Vessel | 0,30 | MPa |
| Water Pressure (Pre) | Expansion Vessel | 0,10 | MPa |
| El. Heater | Type | Sheath | ´ |
| Material | Electric Heater | Stainless Steel | ´ |
| Operation | Electric Heater | Automatic | ´ |
| Capacity | Electric Heater | 3+3 | kW |
| Heat Exchanger | Type | Brazed Plate HEX | ´ |
| Quantity | Heat Exchanger | 1 | ´ |
| Sound Pressure Level | 31 | dB(A) | |
| Outline dimension | (W x H x D) | 500x900x324 | mm |
| Weight | Net / Gross | 52 | kg |
